Ebike Light E-MARK DARKBUSTER E1 (L1e~L6e Class C)

  • Exclusive High-performance Ebike light E-mark Darkbuster E1 includes Dual ECE R113 Class C hi/lo beam & ECE R87 Daytime Running Light & ECE R10 EMC Design.
  • Multiple Certificates means these ebike lights meet the high-end quality of European standard and let you safety riding and legal import and on road.
  • IP68 Waterproof Protection Standard(1 meter) ensure this lights for ebike have excellent performance and long lifespan even under adverse weather conditions.
  • Easy installation and wide application for e-bikes L1e, L2e, L3e(A1), L4e, L5e, L6e & UP TO 11KW/125CC.

All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement.



E-mark ebike light DB E1 icon-5




Exclusive Hi & Lo beam & DRL ebike light with Dual R113 Class C & R87 E-mark Certificate
  • On the market, most ebike lights don’t have E-mark Approved, a very few ebike lights which only passing beam gets E-mark R113 Class B or C.
  • However, BRIGHTSTASRTW Darkbuster E1 is the only one ebike light which Passing Beam & Driving Beam both pass E-mark R113 Class C.
  • Besides that, these lights for ebike also come with E-mark R87 Powerful Daytime Running Light function can ensure you for safety riding.
  • Compact and lightweight ebike lights bring you the best beam pattern(glare-free). Most importantly, it can let you legal import and legal on road.
  • Our ebike light can easily apply with two-wheel powered vehicle(L1e), three-wheel moped(L2e), and two-wheel motorcycle(L3e) & up to 11KW/125CC

E-mark ebike light DB E1 Hi Beam

HI BEAM

E-mark ebike light DB E1 Lo Beam

LOW BEAM






ECE R10 Approved(EMC Compliance Test)
  • Almost 95% ebike light on the market don’t have ECE R10(EMC) E-mark Approved.
  • BRIGHTSTARTW ebike lights DARKBUSTER E1 has excellent EMC design and also passed ECE R10 Approved(EMC Compliance Test).
  • These lights for ebike can operate in an electric environment without interfere other electronic devices, and without being interfered by other devices.



ECE R10 Approved (EMC Compliance Test)



R10: https://www.unece.org/fileadmin/DAM/trans/main/wp29/wp29regs/2019/E-ECE-324-Add.9-Rev.6.pdf

Read More: https://brightstartw.com/blog/why-led-driving-light-has-to-perform-electromagnetic-compatibility-approval/






Waterproof Protection IP 68(1M Depth)
  • E-mark ebike light Darkbuster E1 feature an international standard rating of IP68.
  • This ebike lights are deemed fit enough to withstand dust, sand, dirt, etc.
  • Our lights for ebike are resistant to submersion up to a maximum depth of 1 meters underwater and are more than enough the rider’s demands.

E-mark ebike light DB E1 SEALING TEST




QUALITY ASSURANCE Based on SAE J575 Standards

S14.4.2.3 Heat Test
S14.5.1 Vibration Test
S14.6.6.3 Temperature Cycle Test
S14.6.9 Sealing Test
Salt Spraying Test(ASTM B117-73)

electric bike light DARKBUSTER QUALITY ASSURANCE






Read More Electric Motorcycles Lights E-MARK DARKBUSTER E1

h4 led bulb motorcycle

DB E1 SPEC

Inside ChipOSRAM Chip / LO:13W / HI:14W
Taiwan Highlight Chip / DRL:5W
Color Temperature6000K±500K
Luminous Flux (Raw Lumens)LO:1250LM (330lx) / HI:1550LM (420lx)
DRL: 400LM
Input Voltage9-30V DC / 24-70V DC / OPTIONAL
WeatherproofIP68 (1M)
HousingCNC Machined Aluminum Housing
Operating Temperature-20℃~+60℃
ApplicationsL1e / L2e / L3e(A1) / L4e / L5e / L6e








If The Control Panel Power Is Less Than 12w, A Cable Set With Relay Is Absolutely Necessary. Wiring Shows As Below:

Environmental Test- EMARK ECE 113 Electric Bike Headlight Testing in Lab.
